2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S

2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S
2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S
video play

Large Image :  2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S

Product Details:
Place of Origin: Shenzhen China
Brand Name: ESEN
Certification: ISO9001/ISO14001
Model Number: E286-3796KBWIG01-C24
Document: E286-3796KBWIG01-C24-.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 500 PCS
Price: US$ 2.6（can be negotiated）
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 7~14 working days
Payment Terms: L/C,T/T
Supply Ability: 500K/mth
Contact Now
Detailed Product Description
LCD Size: 2.86inch(Diameter) Display Mode: Normally Black
Resolution: 376(H)RGB X 960(V) Dot Pitch: 0.028(H) X 0.108(V) Mm
Active Area: 26.51(H) X 67.68(V) Mm Module Size: 31.2(H) X 76.6(V) X2.13(D) Mm
Color Arrangement: RGB Vtertical Stripe Interface: MIPI Interface
Drive IC: ST7701S Luminance(cd/m2): 350 (TYP)
Viewing Direction: All View Backlight: 4 White LED
Operating Temp.: -20℃~ + 70℃ Storage Temp.: -30℃~+ 80℃
Weight: 1.2 G
Highlight:

2.86-inch 350cd/m² High-Bright IPS Display

,

Vertical Bar Design for Wearables & Automotive

,

SPI-Driven Ultra-Low Power Operation

2.86 inch Vertical IPS LCD TFT Bar Display Module

350 cd/m² Brightness for Vehicle Recorders, Smart Watches, Wrist-Worn Phones (ST7701S)

Technical Specifications
Attribute Value
LCD Size 2.86inch (Diameter)
Display Mode Normally black
Resolution 376(H)RGB × 960(V)
Dot pitch 0.028(H) × 0.108(V) mm
Active area 26.51(H) × 67.68(V) mm
Module size 31.2(H) × 76.6(V) × 2.13(D) mm
Color arrangement RGB Vertical stripe
Interface MIPI Interface
Drive IC ST7701S
Luminance (cd/m²) 350 (TYP)
Viewing Direction All View
Backlight 4 White LED
Operating Temp. -20℃ ~ +70℃
Storage Temp. -30℃ ~ +80℃
Weight 1.2 g
Product Overview

This 2.86" TFT LCD display module (E286-3796KBWIG01-C24) is a transmissive type color active matrix TFT (Thin Film Transistor) liquid crystal display that uses amorphous silicon TFT as a switching device. The module consists of a TFT LCD panel, driver circuit, and backlight unit, capable of displaying up to 16.7M colors at 370(RGB)×960 resolution.

Mechanical Design
2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S 0 2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S 1 2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S 2

Special Features:

  • Long-strip shape with narrow bezel design
  • All-view direction capability
  • Thin and lightweight structure
Applications

This display module is suitable for various industries including:

  • Consumer Electronics
  • Health & Personal Care
  • Mobile Electronics
  • Automotive (Dashcam Recorders)
  • Wearable Devices (Smart Watches)
  • Medical Equipment (Pulse Oximeters)
  • Industrial Equipment
Manufacturing Capabilities
  • Experienced R&D Department
  • Large Product Line
  • ISO9001 and ISO14001 certified production
  • ODM/OEM services available
  • Buyer specifications accepted
  • Small MOQ accepted
  • Competitive pricing and short lead times
Packaging Specifications
Item Quantity
Module 480 per Primary Box
Holding Trays (A) 15 per Primary Box
Total Trays (B) 16 per Primary Box (Including 1 Empty Tray)
Primary Box (C) 1-4 per Carton (4 as Major/Maximum)
2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S 3 2.86 inch Vertical IPS LCD TFT Bar Display Module 350 cd/m² Brightness for Vehicle Recorders Smart Watches Wrist-Worn Phones ST7701S 4
Frequently Asked Questions
Q: When can I get the quotation?
A: We usually quote within 12 hours after receiving your inquiry. For urgent requests, please contact us directly.
Q: What is your warranty?
A: We provide a one-year warranty on our products.
Q: May I buy samples from you?
A: Yes, sample orders are welcome to evaluate our product quality and service.
Q: How to place bulk orders?
A: Provide specifications → Receive Proforma Invoice → Payment → Production → Delivery as scheduled.
Q: What shipping methods do you offer?
A: We offer multiple options including DHL, UPS, FedEx, TNT, EMS, air cargo, and sea freight.
Q: What about product quality control?
A: We implement rigorous testing processes including IQC, IPQC, and FQC with 100% final inspection.
Q: Do you provide OEM services?
A: Yes, we offer professional OEM services with custom specifications.
Q: Do you have after-sales service?
A: Yes, we provide technical support and firmware updates through our dedicated after-sales department.
