11.6 Inch LCD Screen 1920×1080 EDP Interface Back Folding All Iron Anti Blue Light TFT LCD LCD Module
In order to enable more customers to choose the appropriate LCD screens, ESEN has been cooperating with LCD glass suppliers for a long time. It has developed various display sizes such as TFT LCD, AMOLED LCD, PMOLED LCD, flexible LCD, transparent LCD, etc., including circular, square, and elongated shapes. At the same time, ESEN can customize various touch screens with different shapes, sizes, curvatures, single-point touch, multi-point touch, etc., according to the different application environments of customers' products. Most of our products can be used in smart furniture, smart wearables, mobile phones, industrial control equipment, digital products, medical devices, automotive industrial control, advertising machines, etc. Our featured services: professional customized production, standard screen inventory.
1. Application
This specification applies to a color TFT-LCD Module,
2. Overview
This Open-cell is a color active matrix LCD open-cell incorporating Oxide TFT (Thin Film Transistor).It is composed of a color TFT-LCD panel, driver ICs, a control circuit and power supply circuit. Graphics and texts can be displayed on a 1920×3×1080 dots panel with 16,777,216 colors by using eDP (Embedded Display Port) Ver1.2 interface and supplying +3.3V DC supply voltage for TFT-LCD panel driving. In this TFT-LCD panel, color filters for excellent color performance is incorporated to realize brighter and clearer pictures, making this open-cell optimum for use in multi-media applications. Optimum viewings are in all directions. Without Backlight-driving LED controller. eDP transfer rate specification: 2.7Gbps/2 lane.
Driving interface of PWB
CN1 (eDP signals, +3.3V DC power supply and B/L power supply)
[Note 4-1-1] Don’t input any signals or any powers into a NC pin. Keep the NC pin open.
[Note 4-1-2] The shielding case is connected with signal GND.
・Connector used :20455-030E-76(I-PEX)
・Corresponding connector : 20453-030T (I-PEX)
(Panda is not responsible to its product quality, if the user applies a connector not corresponding to the above model.) The equivalent circuit figure of the terminal.
application area
Q&A
Q: Is there a Touch Panel (Touch Screen) on the display?
A: We can offer you the RTP (Resistive Touch Panel) and CTP (Capacitive Touch Panel) if you need.
Q: What about payment terms?
A: PayPal and credit card can be accepted for sample, T/T paid for mass order. Advance payment percentage can be discussed.
Q: How long can I get the goods?
A: It depends on the quantity. Our inventory is mainly raw materials, semi-finished and a small number of finished products. Samples available in stock will be sent in 3 days; Small batch delivery takes 15-20 working days include producing; Large batch delivery takes 20-30 working days. We will list the time cost for you before order.
Q: Can I trust the quality? We want good quality first.
A: Our company has a professional Quality Control Department, and all products are 100% inspected prior to ship. We welcome all the customers from the wolrd visiting our factory for checking any time
