IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122

IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122
IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122
video play

Large Image :  IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122

Product Details:
Place of Origin: Shenzhen China
Brand Name: ESEN
Certification: ISO9001/ISO14001
Model Number: T050BWV40I1K004
Payment & Shipping Terms:
Minimum Order Quantity: No MOQ
Price: can be negotiated
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 7~14 working days
Payment Terms: L/C,T/T
Supply Ability: 500K/mth
Contact Now
Detailed Product Description
Size: 5.0inch Resolution: 800(horizontal)*480(Vertical)
Interface: RGB-24bit Connector: RGB
Color Depth: 16.7M Technology Type: A-Si
Pixel Pitch (mm): 0.045 X 0.135 Pixel Configuration: R.G.B. Vertical Stripe
Display Mode: Normally Black LCD IC: ILI5960+ILI6122
Viewing Direction: ALL Gray Scale Inversion Direction: FREE
LCM (W X H X D) (mm): 120.7*75.9*3 Active Area(mm): 108 X 64.80
With /Without TSP: Without LED Numbers: 18LEDs
Luminance: 600/cd Operating Temperature: -20℃~ 70℃
Storage Temperature: -30℃~ 80℃ Custom Service: FPC, CTP (capacitive Touch Panel), RTP (resistive Touch Panel), Pin Definition, Packing, HD-MI Board
Highlight:

TFT Customized LCD Panel

,

IPS Customized LCD Panel

,

800x480 custom lcd panel

IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122
Product Specifications
Attribute Value
Size 5.0inch
Resolution 800(horizontal)*480(Vertical)
Interface RGB-24bit
Connector RGB
Color Depth 16.7M
Technology type a-Si
Pixel pitch (mm) 0.045 x 0.135
Pixel Configuration R.G.B. Vertical Stripe
Display Mode Normally Black
LCD IC ILI5960+ILI6122
Viewing Direction ALL
Gray Scale Inversion Direction FREE
LCM Dimensions (W x H x D) (mm) 120.7*75.9*3
Active Area(mm) 108 x 64.80
With/Without TSP Without
LED Numbers 18LEDs
Luminance 600/cd
Operating Temperature -20℃~ 70℃
Storage Temperature -30℃~ 80℃
Custom Service FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board
Product Overview

5.0 Inch 800x480 dots ILI5960 ILI6122 IPS TFT LCD Customized Panel

The T050BWV40I1K004 is a high-quality, 5" TFT LCD display module manufactured by Chenghao Lcd. The module incorporates IPS technology and features a 800x480 resolution, providing high-quality and sharp images. It is a versatile display module that can be widely used in various devices that require color views such as smart coffee machines.

IPS TFT Customized LCD Panel 5 Inch 800x480 Dots ILI5960 ILI6122 0
Key Features
  • High-quality display module with a brightness of 600 cd/m² for excellent visibility in any lighting condition
  • IPS technology provides wide viewing angles for clear viewing from almost any angle
  • Versatile application in various devices including smart coffee machines
  • Wide operating temperature range (-20 ~ +70 ℃) for different environments
  • Certified with RoHS, CE, and FCC for quality assurance
  • Comprehensive one-stop LCD solutions including customization services
Why Choose Our Product?
  • Industry-leading manufacturer with integrated trade services
  • Comprehensive OEM and ODM services available
  • High production capacity of up to 300,000 pieces per month
  • Remote online technical support for prompt after-sales service
  • One-year warranty for customer peace of mind
