3.4'' 800x800 IPS TFT LCD Circular Instrument Screen Round Video HDMI Input Board

3.4 inch 800x800 IPS tft lcd circular instruments screen round display panel Video HDMI input board

Product Description:
3.4 inch ips industrial Instruments Meters lcd round PACP touch screen circular display HDMI board
General Features:
Panel Size: 3.4 inch                                           Panel Type: a-Si TFT-LCD, LCM
Resolution: 800(RGB)×800                               Pixel Format: RGB Vertical Stripe
Display Area: 87.6(W)×87.6(H) mm                  Bezel Opening: 88.6(W)×88.6(H) mm
Outline Size: 99(W)×96.6(H) mm                     Surface: Hard coating (7H)
Brightness: 400 cd/m² (Typ.)                            Contrast Ratio: 800:1 (Typ.) (TM)
Viewing Angle: 80/80/80/80 (Typ.)(CR≥10)     Display Mode: SFT, Normally Black, Transmissive
Best View on: Symmetry                                   Response Time: 25 (Typ.)(Tr+Td)
Display Colors: 16.7M
Frequency: -                                                      Touch Screen: Optional
Application: Industrial, Instruments & Meters, Round Display
Signal Interface: MIPI (3 data lanes) , 39 pins , FPC
Input Voltage: 1.8/5.0/-5.0V (Typ.)(IOVCC/VDD/-VDD)
Environment: Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
Provide Turnkey LCD Display Project Solutions!!!
(Sizes, Resolution, Brightness, Materials, Shapes, Interfaces, Touch etc.)

PINTERFACE SIGNAL
