5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins

5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins
5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins
video play

Large Image :  5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins

Product Details:
Place of Origin: Shenzhen China
Brand Name: ESEN
Certification: ISO9001/ISO14001
Model Number: TS050YMM-J40-HDMI
Payment & Shipping Terms:
Minimum Order Quantity: No MOQ
Price: can be negotiated
Packaging Details: Cartons, Capboard, EPE, Blister Tray.
Delivery Time: 6~14 working days
Payment Terms: L/C,T/T
Supply Ability: 300K/mth
Contact Now
Detailed Product Description
LCD Size: 5.0 Inch LCD IC: HX8399C
Operating Temperature: -20℃~ +60℃ Storage Temperature: -30℃~ +70℃
Active Area: 127.008 (H) ×127.008 (V) Number Of Pixels: 1080(H) RGB × 1080(V)
Pixel Pitch: 0.1176 (H) ×0.1176 (V) Pixel Arrangement: 1pixel 2domain
Display Colors: 16.7 M Color Gamut: 65%(Min.) 70%(typ.)
Display Mode: Normally Black, Transmissive Mode Dimensional Outline: 136.531x132.208x1.98mm
Viewing Direction (Human Eye): U/D/L/R Free Viewing Direction Custom Service: FPC, CTP (capacitive Touch Panel), RTP (resistive Touch Panel), Pin Definition, Packing, HD-MI Board
Highlight:

1080 X 1080 lcd module display

,

5in lcd module display

,

Full View lcd display module

5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins
Product Specifications
Attribute Value
LCD size 5.0 inch
LCD IC HX8399C
Operating Temperature -20℃~ +60℃
Storage Temperature -30℃~ +70℃
Active Area 127.008 (H) ×127.008 (V)
Number of Pixels 1080(H) RGB × 1080(V)
Pixel Pitch 0.1176 (H) ×0.1176 (V)
Pixel Arrangement 1pixel 2domain
Display Colors 16.7 M
Color Gamut 65%(Min.) 70%(typ.)
Display Mode Normally Black, Transmissive mode
Dimensional Outline 136.531x132.208x1.98mm
Viewing Direction U/D/L/R free viewing direction
Custom Service FPC, CTP, RTP, pin definition, packing, HD-MI board
Product Description

The TS050YMM-J40-HDMI is a high-performance 5-inch color active matrix TFT-LCD panel featuring:

  • LTPS TFT technology for active switching
  • Full HD resolution (1080×1080 pixels)
  • 50-pin MIPI interface with HDMI compatibility
  • IPS technology for wide viewing angles
  • 16.7 million color display capability
  • Transmissive display with normally black mode
  • Integrated TFT-LCD panel, driving circuit, and backlight system
5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins 0 5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins 1 5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins 2 5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins 3 5in HD 1080 X 1080 Full View LCD Module Display HDMI MIPI Interface IPS 50 Pins 4
Frequently Asked Questions
What is your company's experience and reputation in the industry?
With 15 years of industry experience, we are recognized for delivering high-quality display modules and exceptional customer service to clients across multiple industries.
Are there any certifications or standards that the product meets?
Our LCD modules meet rigorous industry standards including ISO9001 certification and RoHS environmental compliance.
