5.0 Inch IPS CTP Color Display 800x480 40pin TFT LCD Capacitive Touchscreen

Large Image : 5.0 Inch IPS CTP Color Display 800x480 40pin TFT LCD Capacitive Touchscreen

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	ESEN
Certification:	ISO9001/ISO14001
Model Number:	T050BWV40I3506-CT

Payment & Shipping Terms:

Minimum Order Quantity:	No MOQ
Price:	can be negotiated
Packaging Details:	Cartons, Capboard, EPE, Blister Tray.
Delivery Time:	6~15 working days
Payment Terms:	L/C,T/T
Supply Ability:	300K/mth

Contact Now

Detailed Product Description

Size:	5.0inch	Resolution:	800(horizontal)*480(Vertical)
Interface:	RGB-24bit	Connector:	Connector
Color Depth:	16.7M	Technology Type:	A-Si
Pixel Pitch (mm):	0.045 X 0.135	Pixel Configuration:	R.G.B. Vertical Stripe
Display Mode:	Normally Black	LCD IC:	ST7262
Pin:	40Pin	Viewing Direction:	ALL
Gray Scale Inversion Direction:	FREE	LCM (W X H X D) (mm):	120.775.82.8
Active Area(mm):	108 X 64.80	With /Without TSP:	Without
LED Numbers:	12LEDs	Luminance:	600/cd
Operating Temperature:	-20℃~ 70℃	Storage Temperature:	-30℃~ 80℃
Custom Service:	FPC, CTP (capacitive Touch Panel), RTP (resistive Touch Panel), Pin Definition, Packing, HD-MI Board

5.0 Inch IPS CTP Color Display 800x480 40pin TFT LCD Capacitive Touchscreen

Product Specifications

Attribute	Value
Size	5.0inch
Resolution	800(horizontal)*480(Vertical)
Interface	RGB-24bit
Connector	40Pin
Color Depth	16.7M
Technology type	a-Si
Pixel pitch (mm)	0.045 x 0.135
Pixel Configuration	R.G.B. Vertical Stripe
Display Mode	Normally Black
LCD IC	ST7262
Viewing Direction	ALL
Gray Scale Inversion Direction	FREE
LCM Dimensions (W x H x D) (mm)	120.775.82.8
Active Area(mm)	108 x 64.80
With/Without TSP	Without
LED Numbers	12LEDs
Luminance	600/cd
Operating Temperature	-20℃~ 70℃
Storage Temperature	-30℃~ 80℃
Custom Service	FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board

Product Description

T050BWV40I3506-CT is a 5.0 inch color display installed on live broadcast equipment, which supports multi-touch functionality. Users can easily interact with the display by pressing the touch panel.

This display has undergone rigorous high and low temperature testing, ensuring normal operation in environments ranging from -20℃ to +70℃ (wide temperature display).

This cost-effective touch display combines a TFT LCD panel with a touch panel (TP). The LCD panel is TN type, requiring users to view content clearly at a 12 O'clock viewing angle. The capacitive touch panel (CTP) uses I2C interface.

The 5.0 inch display area features a resolution of 800xRGBx480, capable of displaying 16M colors, and supports 24-bit RGB interface.

Input/Output Terminals

Absolute Maximum Ratings

The following are maximum values which, if exceeded, may cause faulty operation or damage to the unit.

Parallel 24-bit RGB Input Timing (PVDD=VDD=VDDI= 3.3V, AGND= OV, TA=25°C)

Frequently Asked Questions

Q1: Are you manufacturer?

A: Yes, we are manufacturer.

Q2: How long is your delivery time?

A: Normally 3-5 working days after payment; Special requirement orders, delivery time is negotiable.

Q3: If the products can't work after receiving it, what should I do?

A: We will replace new items for you at once and then we make the judgement for the issue.

Q4: Do you accept OEM design?

A: Yes, we do. We can design according to your requirement, MOQ usually 100-1000.

Q5: Do you accept pay 30% in advance?

A: Yes, we do. We can start to prepare your goods when receive 30% payment, and send them after get the rest 70% payment.
