7.0 Inch 1024x600 IPS TFT LCD Display 1500nits Sunlight Readable High Brightness

Large Image : 7.0 Inch 1024x600 IPS TFT LCD Display 1500nits Sunlight Readable High Brightness

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	ESEN
Certification:	ISO9001/ISO14001
Model Number:	TX070IPS-2650RB-HDMI

Payment & Shipping Terms:

Minimum Order Quantity:	No MOQ
Price:	can be negotiated
Packaging Details:	Cartons, Capboard, EPE, Blister Tray.
Delivery Time:	6~14 working days
Payment Terms:	L/C,T/T
Supply Ability:	300K/mth

Contact Now

Detailed Product Description

LCD Type:	7 Inch	Dimensional Outline:	163.8(W)x97(H)x2.6(D)
Active Area:	154.2144(W)x 85.92(H)	Pixel Size:	50.2(W)xRGBx143.2(H)
Resolution:	1024(RGB)x600	Luminance:	1500cd/m2
Surface Treatment:	Glare	Display Color:	16.7M
Viewing Direction:	IPS	Operating Temperature:	-20--+70/-30--+85(℃)
Storage Temperature:	-30--+80/-40--+90(℃)	Active Area(WxH):	Drawing
Backlight:	3*7-LEDs (white)	Data Transfer:	MIPI
Voltage:	2.8V To 3.3V	Interface:	I2C/USB
Custom Service:	FPC, CTP (capacitive Touch Panel), RTP (resistive Touch Panel), Pin Definition, Packing, HD-MI Board
Highlight:	7.0'' TFT LCD Display , 1024x600 TFT LCD Display , 1500 nits display tft touch

7.0 Inch 1024x600 IPS TFT LCD Display 1500nits Sunlight Readable High Brightness

Product Specifications

Attribute	Value
LCD Type	7 inch
Dimensional outline	163.8(W)x97(H)x2.6(D)
Active area	154.2144(W)x85.92(H)
Pixel size	50.2(W)xRGBx143.2(H)
Resolution	1024(RGB)x600
Luminance	1500cd/m²
Surface Treatment	Glare
Display color	16.7M
Viewing Direction	IPS
Operating temperature	-20℃ to +70℃/-30℃ to +85℃
Storage temperature	-30℃ to +80℃/-40℃ to +90℃
Backlight	3*7-LEDs (white)
Data Transfer	MIPI
Voltage	2.8V to 3.3V
Interface	I2C/USB
Custom Service	FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board

Product Overview

High brightness 1500-nit 7-inch in-vehicle display screen with excellent sunlight readability

MIPI interface ensures high-speed data transfer for smooth display performance

IPS technology provides 360-degree rotation capability and wide viewing angles

1024×600 resolution delivers sharp, clear visuals with rich, accurate colors

Ideal for automotive applications requiring stable visual performance in various lighting conditions

Frequently Asked Questions

Are you a manufacturing company or a trading company?

We are a manufacturing company with factories located in Shenzhen, Dongguan, and Jiangxi.

How can we obtain the samples?

The process for obtaining samples is as follows: Send an inquiry → Receive a quotation → Confirm the quotation and pay the mold fee → Provide technical drawings → Confirm the drawings → Manufacture the mold and produce samples → Complete the samples → Deliver via freight or sea transportation.

How long will it take to receive the samples?

Wireframe drawing preparation takes 2-3 business days. Sample production time is approximately 10-15 business days.

Will you provide free samples?

Yes, we typically provide 1-3 free samples per order. However, the mold fee must be covered by the client.

Can you design LCD displays according to our specifications?

Absolutely. We specialize in custom designs and offer competitive mold fees tailored to your requirements.

What is the process for placing an order?

Once the samples have been approved, please submit your official purchase order via email or fax. Upon receipt, we will issue an invoice for the deposit. To proceed, we require the following details regarding your order:
1) Product information: quantity and part numbers
2) Delivery schedule preferences
3) Logistics information: company name, address, postal code, phone and fax numbers, and destination port
4) If applicable, please provide contact details for your freight forwarder in China.

How long does mass production take?

Mass production typically requires 25-30 business days. This timeline may vary depending on the specific order quantities and part numbers.
